IG-001
| Mounting / Installation | |
| Wire Lead | 3' SPT-2W/18AWGx2C wire lead. |
| Mounting | Installing in areas with high foot traffic is acceptableLens is not drive-over rated |
| Material | |
| Housing | D2" solid brass cover, Black anti-impact ABS housing |
| Lid | Clear glass lens, Angled side cut for easy mounting,Stationary stainless steel gimbal ring to hold the lamp strongly |
| Socket | Low voltage lamp holder, Direct burial cable |
| Finish | Antique brass |
LIGHT SOURCE OPTIONS
Choose from:
• Factory-installed Smart PAR36(ARlll) lamp below
• Also available without lamp
• PAR36 Lamp IP rating 67
| Watage | 11W |
| Voltage | 12V AC/DC |
| Lumen Output | 900 lm at 3000K |
| Beam Spread | 40° |
| CCT Options | RGB TW, TW=2200K-6500K |
| RGBW Options | Infinite color selection via color wheel, quick presets for red ,green,blue,amber,purple etc. |
| Dimming | 0-100% dimming |
| IP | 67 |
| Fixture | Finish Option |
|---|---|
| KI0003B | -BLK for black over-coat -AB for antique brass |
